Single-Stage Coal Gasifier Cold Clean Gas Station [Anthracite]
넶PV：0
Created on：2026-09-26 15:27
The raw gas generated by the coal gasifier, at a temperature of 500–600°C, enters the twin-pipe cooler where it is cooled by circulating water. The dust in the gas is washed down and discharged through the water seal at the bottom of the vertical pipe. The outlet gas temperature is approximately 80–90°C. It then enters the scrubber for further cooling and dust removal, bringing the gas temperature down to 35–45°C. After that, the gas passes through the electrostatic precipitator for oil and dust removal, is pressurized by the gas booster, and further dewatered and detarred in the droplet separator before being delivered to the end users.
